Tru-Test ID5000 Livestock Scale Indicator | Free Shipping & Fall Rebate Offer!
$ 1,889.99
Availability: Instock

Tru-test ID5000 Scale Indicator

FREE USA SHIPPING!

* SPECIAL FALL REBATE OFFER UNTIL NOVEMBER 30, 2019

Get a $300 Visa gift card, 2 bags of custom Z-Tags Stockman tags, and a Z2 tagger with the purchase of the ID5000 indicator through November 30. See the Tru-Test promotions page for details and redemption form.TRUTEST SCALE REBATE

* CLICK THIS LINK TO PRINT OUT REBATE FORMS.

Weighing decisions made easy.

Quickly capture accurate animal weights to provide information you can act on to maximise profitability. Use it to identify poor performers, catch health issues early or easily split your animals into groups.

Tru-Test’s unique Superdamp 4™ weighing technology locks onto the weight of the liveliest animals faster than ever before. Combined with a rugged design, suitable for even the most extreme outdoor environments, Tru-Test’s weigh scale indicators have earned a global reputation as the animal weight capture and data management solution.

And now we have developed the next generation. The 5000 series.

The ID5000 is faster to set up and access information, with a high brightness screen that is clearly visible in the yards. It also has more options to speed up data transfer and increased storage capacity.

It’s never been easier to track the performance of your animals and make better informed decisions.



FEATURES AND SPECIFICATIONS

  • Record what you need. Capacity to store up to 250 thousand records in 250 weighing sessions. For each animal you can record up to 3 IDs and 3 pieces of information (other than weight).
  • Track performance. Calculate and visualize an animal’s weight gain.

  • Sorting. Sort animals into groups. Up to 5 groups can be created based on weight, weight gain, or other single criteria.

  • Screen viewable in all light conditions. The 7" high brightness display automatically switches between indoor and outdoor mode making it viewable even in the harshest light conditions.

  • Proven speed. Tru-Test’s unique Superdamp 4TM technology locks onto the weight of a moving animal faster than any other indicators on the market.

  • Navigate and enter information quickly. Quick access keys and keypad avoids obscuring screen with dirty ngers.

  • Simple and quick to set up. Use the pre-de ned setups or save your own setups to easily switch between jobs. Built-in step-by-step instructions and pop-ups help provide on-the-spot support if needed.

  • Easily transfer recorded information. No matter where you are you can quickly transfer information using your mobile device (Android* or Apple*), USB ash drive or computer (Microso Windows*).

  • More rugged than ever. The new water, dust and shock proof IP67 case with rubber bumpers is the latest in rugged design based on 30 years of experience designing products for livestock use. We have made the tough even tougher.

  • Long Battery Life. 10 hrs with backlight on and 13 hrs with backlight

  • Connect to other equipment. Link wirelessly or by cables to other devices such as Electronic ID readers, auto dra ers/ sorters and more. Bluetooth® Class 1 wireless interface connects to devices up to 300' (100 m ) away. Wi-Fi* (IEEE* 802.11 b/g/n) wireless access point interface for connection from Apple or Android mobile and or tablet devices only. The standard connections are 1 x USB, 1 x mini-USB, and 1 x C16 for power and serial. C16 optional adaptor cables allow up to 3 connections – 2 serial, 1 power.

  • Size. WxHxD 10.25" x 9" x 2.5"

  • Weight. 3.85 lb

INCLUDES

  • Hard plastic carry case,
  • 110v mains power adaptor,
  • USB cable,
  • USB flash drive
  • adjustable mounting bracket.

DOWNLOAD USER MANUAL













Software Downloads

At Tru-Test, we spend a huge amount of time developing and enhancing our software. By upgrading you can take advantage of these updates.

Before updating software we recommend you backup the important information stored on your device. The software update process will keep your indicator files intact. But in case of the unlikely event of an update failure you should download your data to your computer.

Data Link can be used to easily check our website for software updates for both itself and for connected Tru-Test devices (All except 3000-series weigh scale indicators). Open Data Link then click on Tools>Updates...>Check for updates.

Alternatively you can download the latest software (device firmware) using the links below (this will take a few more clicks). Click on the yellow arrow to the left to download the software file for your product. All of our software files are provided in “zipped” folders for easy downloading and additional safety.

How do I “unzip” the software files?

  • Click on the icon to download the zip file and select a known location to save the file on your PC.
  • Once the download is complete, right click on the file and select the "Extract All" option, saving to the same location.

XR5000 & ID5000 Firmware Update

After the download is complete open Data Link to update the software on your device. In Data Link click Tools>Updates>Update device firmware from a file then follow the on screen instructions to find the update file.
